Central Lithium batteries are designed with high efficiency charging & discharging with more than 6000 times cycle life to ensure uninterrupted & longer life span. .
| Model: CBR51.2V 100-AH | |
|---|---|
| Nominal Voltage | 51.2V |
| Nominal Capacity | 100Ah |
| Nominal Energy | 5.12kw |
| Standard Charging Current | 20A |
| Max. Continuous Charging Current | 100A |
| Standard Discharge Current | 50A |
| Continuous Discharge Current | 100A |
| Peak Discharge Current | 200A (3s) |
| Discharge Cut-off Voltage / Charge Temp. Range | 42V ~ 60°C |
| Discharge Temperature Range | -20°C ~ 65°C |
| Storage Temperature Range | -5°C ~ 40°C |
| Storage Humidity / Size (L×W×H) | 65 ± 20% RH / 520×495×175mm |
| Package Size (L×W×H) | 550×520×230mm |
| Net Weight | 44kg |
| Gross Weight | 46kg |
| Cycle Life | > 6000 times |
| SOC Indication | LED Light |
| Communication Mode | RS485 / CAN |
