Central half-cut / double glass module, assembled with multi-busbar PERC technique and half-cut structure, which can not only absorb the energy from the front of the module, but also absorb the reflected light and the scattered light from the back, offer the advantages of higher power output, reduce shading effect on the energy generation, enhance the mechanical load bearing capacity as well.
| Model Type | ESP585-36V | ESP595-36V | ESP600-36V |
|---|---|---|---|
| Rated Peak Power-Pmax (Wp) | 585.00 | 595.00 | 600.00 |
| Maximum Power Voltage-Vmp (V) | 44.81 | 44.93 | 44.99 |
| Maximum Power Current-Imp (A) | 13.05 | 13.24 | 13.34 |
| Open Circuit Voltage-Voc (V) | 52.72±3% | 52.86±3% | 52.93±3% |
| Short Circuit Current-Isc (A) | 13.87±3% | 14.07±3% | 14.17±3% |
| Module Efficiency (%) | 22.65 | 23.03 | 23.23 |
| Model Type | ESP585-36V | ESP595-36V | ESP600-36V |
|---|---|---|---|
| Rated Peak Power-Pmax (Wp) | 648.00 | 659.00 | 665.00 |
| Maximum Power Voltage-Vmp (V) | 44.95 | 45.07 | 45.07 |
| Maximum Power Current-Imp (A) | 14.42 | 14.63 | 14.74 |
| Open Circuit Voltage-Voc (V) | 52.88±3% | 53.02±3% | 53.09±3% |
| Short Circuit Current-Isc (A) | 15.33±3% | 15.55±3% | 15.66±3% |
| Cell Type (mm) | 182×91 N-Type Mono |
| No. of Cells | 144 (12×12) |
| Module Dimensions (mm) | 2278×1134×30 |
| Weight | 31.50 kg |
| Bifacial Glass Front | 2.0 mm AR Coating Tempered Glass |
| Bifacial Glass Back | 2.0 mm Glazed Glass |
| Frame | Anodized Aluminum Alloy (Silver) |
| Junction Box | IP68, 1500VDC, 3 Schottky Bypass Diodes |
| Cables | 4.0mm², (+)300mm / (-)300mm |
| Connector | IP68 |
| Snow Load/Wind Load | 5400Pa / 2400Pa |
| Class of Safety Protection | Class A |
| IEC Component Fire Rating | Class A |
| Maximum System Voltage | 1500V |
| Operational Temp | -40~+85°C |
| Max Series Fuse Rating | 25A |
| Nominal Module Operating Temp (NMOT) | 45±2°C |
| Temp Coefficient of Pmax | -0.290% / °C |
| Temp Coefficient of Voc | -0.250% / °C |
| Temp Coefficient of Isc | +0.045% / °C |
| Number of Modules per Pallet | 37 |
| Number of Pallets per Container | 20 |
| Number of Modules per Container | 740 |
